Description
Ditting 1203 Grinder
CaffeTech Canada presents the Ditting 1203 Grinder. Built to Last with dual capacitor motor that charges up the massive 1210 mm grinding flat burr disks. In the Ditting product portfolio for countless years and with very few renditions of its current style, the Ditting 1203 acts perfectly in roaster coffee bars where grinding bags of coffee are ongoing and the demand of high production grinding is necessary.
The Ditting 1203 offered through CaffeTech have specialty burrs that are unique to Ditting and offer the user a wide range of grinding styles that can meet a variety of consumer requirements. The Ditting 1203 has wear- resistant steel burrs, aroma saving consistent grinding and stepless grind adjustment.
Complete with manual knocker and bag shaker, the vertical design of the Ditting 1203 provides very low retention. Easy to clean and simple to operate please contact Sales@caffetech.com for more information on the Ditting 1203 and to learn more about other Ditting grinders that can suit your professional coffee bar needs.
Video
Features
-
Specially developed burrs allow high grinding capacity for all grind adjustment steps
-
Wear-resistant steel burrs
-
Aroma saving consistent grinding
-
Stepless grind adjustment
-
Minimal retention of coffee residues left inside the slide thanks to the manual knocker
-
Bag shaking unit ensures an optimal filling of the bags
-
Very easy to maintain and to clean
Specifications
| Country of Origin: | Germany |
| Burr Material: | Wear-Resistant Steel |
| Burr Size: | 120 mm |
| Burr Life: | 25,000 lbs |
| Hopper Capacity: | 2.4 lbs |
| Grind Speed: | 1400 g/min |
| RPM: | 1400 (50Hz) |
| Power: | 120V/1600W/13A |
| Motor: | 1.8HP |
| Dimensions: | 34 in. (H) x 12.5 in. (W) x 16 in. (D) |
| Weight: | 88 lbs |
Ditting Grinder Comparison Chart
| Model: | 807 Retail | 807 Filter | 807 Lab Sweet | KR1203 Retail | KR1403 Retail | KFA1403 Retail | KFA1403 Industrial |
|---|---|---|---|---|---|---|---|
| Application: | Retail bag grinding, up to 30lbs per day | Retail bag & batch brew basket grinding, up to 30lbs per day. | Retail bag grinding & single dosing for cupping, pour over or espresso, up to 30lbs per day | Retail bag grinding, up to 60lbs per day | Retail bag grinding, up to 100lbs per day | Roasting facilities, up to 100lbs per day. | Roasting facilities, up to 100lbs per day. |
| Hardware: | Vibrating plate | Adjustable forks & slide chute | Folding platform, metal grounds catch | Vibrating plate | Vibrating plate | Extended chute, slide gate | Extended chute, built-in shutoff valve |
| Grind Size Range: | 130µm-1,400µm | 130µm-1,400µm | 100µm-1,200µm | 300µm-900µm | 200µm-1,100µm | 200µm-1,100µm | 200µm-1,100µm |
| Output (lbs/min/800µm): | 2 | 2 | 2 | 5 | 8 | 8 | 8 |
| Burr Lifespan (lbs): | 5,500+ | 5,500+ | 15,000+ | 15,000+ | 15,000+ | 15,000+ | 15,000+ |
| Hopper Capacity (lbs): | 1.1 | 1.1 | 1.1 | 2.4 | 2.4 | 2.4 | 22 |
| Duty Cylcle: | 45 Sec On/180 Sec Off | 45 Sec On/180 Sec Off | 45 Sec On/180 Sec Off | Continuous run | Continuous run | Continuous run | Continuous run |
| Power: | 120v, 60hz, Single Phase, 6A | 120v, 60hz, Single Phase, 6A | 120v, 60hz, Single Phase, 6A | 120v, 60hz, Single Phase, 13A | 220v, 60hz, Three Phase, 10A | 220v, 60hz, Three Phase, 10A | 220v, 60hz, Three Phase, 10A |
| Dimensions WxDxH (inches): | 9 x 14 x 27 | 9 x 14 x 27 | 9 x 14 x 27 | 12 x 16 x 34 | 12 x 16 x 34 | 12 x 16 x 34 | 13 x 16 x 29 |
Resources
Ditting 1203 Brochure
Ditting Product Range
THE DITTING PRODUCTS SHIPS FROM EDMONTON – ALBERTA CANADA – WARRANTY SUPPLIED BY CAFFETECH CANADA
